| Model and Ratings | ||||
| Model | Voltage（V） | Current（A） | Ripple (mV) | Av. Eff. (%)Min |
| PoE35-XXA | 54.0 | 0.01-0.65 | 200 | 85.0 |
| 48.0 | 0.01-0.65 | 200 | 85.0 | |
| Others | ||||
| Input Voltage Range | 90-264VAC | |||
| Input Current | 1.0A | |||
| Output Voltage Tolerance | ±5% | |||
| Safety Standard | CCC(GB4943.1), cULus(UL62368-1), CE(EN62368-1), EAC(IEC62368-1), CB(IEC62368-1), PSB(IEC62368-1) | |||
| Environmental | ||||
| Operating Temperature | -40~50℃ | |||
| Storage Temperature | -40~70℃ | |||
| Operating Humidy | 5% to 95% non condensing | |||
| General | ||||
| Weight | 250g | |||
| Dimensions | 172.o(L) 62.0(W) 30.6(H)mm | |||
| MTBF | 500,000 hours at full load at 25℃ ambient, caculated per Telcordia SR332 | |||
Pin Connections
