| Model and Ratings | |||||
| Model | Voltage（V） | Current（A） | Rated power | Ripple & Noise(max) | Voltage Tolerance |
| UES150-XXXYYYSPA-OP | 12.00 | 0.01-11.00 | 132.0W | 100mVpk-pk | ±5% |
| 15.00 | 0.01-9.00 | 135.0W | 100mVpk-pk | ||
| 18.00 | 0.01-8.00 | 144.0W | 120mVpk-pk | ||
| 24.00 | 0.01-6.00 | 144.0W | 120mVpk-pk | ||
| 36.00 | 0.01-4.00 | 144.0W | 120mVpk-pk | ||
| 48.00 | 0.01-3.12 | 150.0W | 120mVpk-pk | ||
| Input | |||||
| Input Voltage Range | 90-264VAC | ||||
| Frequency Range | 47-63Hz | ||||
| Input Current | 2.0A at 100VAC | ||||
| Inrush Current | 120A max at 240VAC cold start | ||||
| Touch Leakage Current (max) | ≤100μA at 264VAC | ||||
| Environmental | |||||
| Operating Temperature | -30 ℃ to 70 ℃(50℃ to 70℃ refer to derating curve) | ||||
| Storage Temperature | -40 ℃ to 80 ℃ | ||||
| Operating Humidity | 5% to 90% RH, non-condensing | ||||
| Storage Humidity | 5% to 95% RH | ||||
| Operating Altitude | 5,000m | ||||
| General | |||||
| Dimensions | 101.6(L) 50.8(W) 32.0(H)mm | ||||
| Weight | 180g | ||||
| MTBF | ＞200,000hrs MIL-HDBK-217 at 25℃ | ||||
Mechanical Details
