| Model and Ratings | ||||
| Model | Voltage（V） | Current（A） | Ripple (mV) | Av. Eff. (%)Min |
| UES24LZ-120YYYSPA | 12.0 | 0.01-2.00 | 120 | 86.8 |
| YYY： 001-200 stand for current 0.01-2.00A | ||||
| Others | ||||
| Input Voltage Range | 90-264VAC | |||
| Input Current | 0.7A | |||
| Standby Power | 0.075W MAX | |||
| Output Voltage Tolerance | ±5% | |||
| Safety Standard | cULus(UL62368-1), CCC(GB4943.1), CB(IEC62368-1), RCM(AS/NZS62368.1), EAC(ICE62368-1), FCC(Part 15), CE(EN62368-1) | |||
| Environmental | ||||
| Operating Temperature | -10~45℃ | |||
| Storage Temperature | -40~70℃ | |||
| Operating Humidy | 5% to 95% non condensing | |||
| General | ||||
| Weigh | About 125g | |||
| Dimensions | CN/US:60.0*L) 50.0(W) 29.5(H)mm UK: 70.0(L) 50.0(W) 29.5(H)mm | |||
| MTBF | 100,000 hours at full load at 25℃ ambient, calculated per MIL-HDBK-217 | |||
