| Model and Ratings | ||||
| Model | Voltage（V） | Current（A） | Ripple (mV) | Av. Eff. (%)Min |
| UES130DZ-540YYYSPA | 54.0 | 0.01-2.4 | 540 | 89.00 |
| YYY: 001-240 stand for current 0.01-2.4A | ||||
| Others | ||||
| Input Voltage Range | 90-264 VAC | |||
| Input Current | 2.0A | |||
| Output Voltage Tolerance | ±5% | |||
| Standby Power | 0.21W MAX | |||
| Safety Standard | CB(IEC62368-1), CCC(GB4943.1), TUV SUD-NRTL(UL62368-1) | |||
| Environmental | ||||
| Operating Temperature | 0~40℃ | |||
| Storage Temperature | -40~70℃ | |||
| Operating Humidy | 5% to 90% non condensing | |||
| General | ||||
| Weigh | About 360g | |||
| Dimensions | 145.1(L) 69.5(W) 25.5(H)mm | |||
| MTBF | 100,000 hours at full load at 25℃ ambient, calculated per MIL-HDBK-217 | |||
